KONTAKTOR 9A AC3.24VDC LAV EFFEKT, SPOLE UNDER
Produktnummer: 100-C09UEJ10
Produktstatus:
inkl. mva.
100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Load Side, 9A, 1 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack
Contactor, 9 A, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open Poles, 24V DC Electronic, 1 NO Contacts & 0 NC Contacts, Single Pack, Load Side Coil Termination, Screw Terminals, Motor Load
Egenskaper for produkt/familie
- RoHs compliant
- Provides front and side mounting of auxiliary contacts
- Offers common accessories for all contactor sizes
- Includes reversible coil terminations (line or load side)
- Includes built-in surge suppression with DC coils
- Includes space-saving coil-mounted control modules
- Provides IP2X finger protection
- Provides reversible coil terminations (line or load side)
- Includes electronic and pneumatic timing modules
- Meets IEC, UL, and CSA standards requirements
| Spesifikasjoner | |
|---|---|
| Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
| Electrical Standards | UL |
| Contact Configuration | 1 N.O. 0 N.C. Auxiliary Contact Configuration |
| Terminal Type | Screw Terminals |
| Coil Voltage | 24V DC Electronic Coil |
| Rated Operating Current, AC-3 | 9A |
| Package Quantity | 1 |
| Coil Termination | Load Side |
| Interlock | None |
| Right Side Auxiliary Contact | None |
| Front Mounted Auxiliary Contact | None |
| Left Side Auxiliary Contact | None |
| 100-C or 104-C Contactor | 1_ |
| 1-Phase HP (60 Hz) 230V Rating | 1.5 |
| Connection | Screw Terminals |
| 3-Phase HP (60 Hz) 575V Rating | 7.5 |
| 1-Phase HP (60 Hz) 115V Rating | 0.5 |
| Actual Life | Actual Life Cannot be Calculated (more information)... |
| Opprinnelsesland | CH |
| Tolltariffnummer | 85364190 |
| Lengde | 9.601 |
| Høyde | 5.004 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
Repair Parts List Filnavn: 100C-104C-100LC_Parts%20rp.pdf Filtype: application/pdf |
Last ned | |
|
2D Drawing (DWG/DXF) Filnavn: 100-C_FS0_AC_DCE.dxf Filtype: image/vnd.dxf |
Last ned | |
|
3D Mechanical Drawing (PDF) Filnavn: A-B.100-C_FS0_UE_10_3D.pdf Filtype: application/pdf |
Last ned | |
|
2D Drawing (PDF) Filnavn: 100-C_FS0_AC_DCE.pdf Filtype: application/pdf |
Last ned | |
|
MCS 100-C Contactor Photo Filnavn: 100C_23_Ph.jpg Filtype: image/png |
Last ned | |
|
ABMSA090.dwg Filnavn: ABMSA090.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA090.dxf Filnavn: ABMSA090.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA090.pdf Filnavn: ABMSA090.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA090.wmf Filnavn: ABMSA090 Filtype: application/x-msmetafile |
Last ned | |
|
ABMSA091.dwg Filnavn: ABMSA091.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA091.dxf Filnavn: ABMSA091.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA091.pdf Filnavn: ABMSA091.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA091.wmf Filnavn: ABMSA091 Filtype: application/x-msmetafile |
Last ned |
