KONTAKTOR 9A AC-3 24VDC LAV EFFEKT
Produktnummer: 100-C09EJ01
Produktstatus:
inkl. mva.
100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 9A, 0 N.O. 1 N.C. Auxiliary Contact Configuration, Single Pack
Contactor, 9 A, IEC, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open Poles, 24V DC Electronic, 0 NO Contacts & 1 NC Contacts, SinglePack, Line Side Coil Termination, Screw Terminals, Motor Load
Egenskaper for produkt/familie
- Meets IEC, UL, and CSA standards requirements
- Provides front and side mounting of auxiliary contacts
- RoHs compliant
- Provides reversible coil terminations (line or load side)
- Provides IP2X finger protection
- Offers common accessories for all contactor sizes
- Includes built-in surge suppression with DC coils
- Includes reversible coil terminations (line or load side)
- Includes space-saving coil-mounted control modules
- Includes electronic and pneumatic timing modules
| Spesifikasjoner | |
|---|---|
| Interlock | None |
| Front Mounted Auxiliary Contact | None |
| Left Side Auxiliary Contact | None |
| Right Side Auxiliary Contact | None |
| 100-C or 104-C Contactor | 2_ |
| 3-Phase HP (60 Hz) 575V Rating | 7.5 |
| 1-Phase HP (60 Hz) 115V Rating | 0.5 |
| Connection | Screw Terminals |
| 1-Phase HP (60 Hz) 230V Rating | 1.5 |
| Actual Life | Actual Life Cannot be Calculated (more information)... |
| Electrical Standards | UL |
| Coil Voltage | 24V DC Electronic Coil |
| Contact Configuration | 0 N.O. 1 N.C. Auxiliary Contact Configuration |
| Terminal Type | Screw Terminals |
| Coil Termination | Line Side |
| Rated Operating Current, AC-3 | 9A |
| Package Quantity | 1 |
| Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
| Opprinnelsesland | CH |
| Tolltariffnummer | 85364190 |
| Lengde | 9.296 |
| Høyde | 4.902 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
MCS 100-C Contactor Photo Filnavn: 100C_23_Ph.jpg Filtype: image/png |
Last ned | |
|
2D Drawing (PDF) Filnavn: 100-C_FS0_AC_DCE.pdf Filtype: application/pdf |
Last ned | |
|
2D Drawing (DWG/DXF) Filnavn: 100-C_FS0_AC_DCE.dxf Filtype: image/vnd.dxf |
Last ned | |
|
Repair Parts List Filnavn: 100C-104C-100LC_Parts%20rp.pdf Filtype: application/pdf |
Last ned | |
|
3D Mechanical Drawing (PDF) Filnavn: A-B.100-C_FS0_E_01_3D.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA170.dwg Filnavn: ABMSA170.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA170.dxf Filnavn: ABMSA170.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA170.pdf Filnavn: ABMSA170.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA170.wmf Filnavn: ABMSA170 Filtype: application/x-msmetafile |
Last ned | |
|
ABMSA171.dwg Filnavn: ABMSA171.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA171.dxf Filnavn: ABMSA171.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA171.pdf Filnavn: ABMSA171.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA171.wmf Filnavn: ABMSA171 Filtype: application/x-msmetafile |
Last ned |
