KONTAKTOR 2NO+2NC.230V50/60

Produktnummer: 100-C09KF200
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 9A, 2 N.O. 2 N.C. Main Contact Configuration, Single Pack

Contactor, 9 A, 230V 50/60 Hz, AC, 2 NO Poles & 2 NC Poles, 230V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
Spesifikasjoner
Electrical Standards UL
Right Side Auxiliary Contact None
Left Side Auxiliary Contact None
Interlock None
Front Mounted Auxiliary Contact None
100-C or 104-C Contactor None
Actual Life Actual Life Cannot be Calculated (more information)...
Contact Configuration 2 N.O. 2 N.C. Main Contact Configuration
Coil Termination Line Side
Package Quantity 1
Rated Operating Current, AC-3 9A
No. of Poles 4 Poles
Coil Voltage 230V 50/60Hz
Terminal Type Screw Terminals
Utilization Category AC-3 Squirrel-cage motor starting and stopping
1-Phase HP (60 Hz) 115V Rating 0.5
Connection Screw Terminals
1-Phase HP (60 Hz) 230V Rating 1.5
3-Phase HP (60 Hz) 575V Rating 7.5
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 9.296
Høyde 4.801
Livssyklus Active
