Produktnummer: 100-C16UEJ10

inkl. mva.

100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Load Side, 16A, 1 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack

Contactor, 16 A, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open Poles, 24V DC Electronic, 1 NO Contacts & 0 NC Contacts, Single Pack, Load Side Coil Termination, Screw Terminals, Motor Load
Actual Life Actual Life Cannot be Calculated (more information)...
Utilization Category AC-3 Squirrel-cage motor starting and stopping
3-Phase kW (50 Hz) 230V Rating 5.5
3-Phase HP (60 Hz) 575V Rating 15
3-Phase kW (50 Hz) 500V Rating 7.5
Connection Screw Terminals
3-Phase HP (60 Hz) 460V Rating 10
3-Phase kW (50 Hz) 400V/415V Rating 7.5
3-Phase kW (50 Hz) 690V Rating 7.5
Terminal Type Screw Terminals
Coil Termination Load Side
Package Quantity 1
Rated Operating Current, AC-3 16A
Coil Voltage 24V DC Electronic Coil
Contact Configuration 1 N.O. 0 N.C. Auxiliary Contact Configuration
Electrical Standards UL
100-C or 104-C Contactor 1_
Right Side Auxiliary Contact None
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
Interlock None
Opprinnelsesland CH
Tolltariffnummer 85364190
Lengde 9.398
Høyde 4.699
Livssyklus Active
