Guardmaster MSR35H Safety Relay
Produktnummer: 440R-D23201
Produktstatus:
inkl. mva.
Safety Relay, MSR35H, 24V DC, Fixed, 22.5MM Housing Width, 0.5sec, 0 Safety Output, 2 N.O. Solid State Output, CAT 4 Rated
Egenskaper for produkt/familie
- Provides logic units for monitoring and interfacing two-hand control devices with a safety-related circuit
- Offers microprocessor-based models with safety-rated, solid-state outputs
- Compatible with mechanical switches and the Bulletin 800Z Zero-Force Touch Buttons™ (based on model)
| Spesifikasjoner | |
|---|---|
| Output | 2 N.O. Solid State |
| Inputs | Two-Hand Control |
| Immediate Safety Outputs | 2 N.O. Solid State |
| Immediate Auxiliary Outputs | 1 N.O. Solid State |
| Delayed Safety Outputs | N/A |
| Power Supply | 24V DC SELV |
| Reset | Automatic/Manual Reset |
| Removable Terminals | Fixed |
| Relay Model Selected | MSR35H/HP |
| Lengde | 10.109 |
| Høyde | 2.794 |
| Livssyklus | Discontinued |
