ArmorPoint ProfiBus Network Adaptor
Produktnummer: 1738-APB
Produktstatus:
inkl. mva.
1738 ArmorPoint Communication Adaptor, Profibus DP, M12 Quick-Disconnect ,Input Voltage Range: 10-28V DC Field Side Power Requirements: 24 V DC (+20% = 28.8V DC) @ 400mA -8.0W Power Consumption(W) at 24V: 8.0W Inrush Current: 6 A for 10ms Power Dissipation, Max.: 2.8 W @ 28.8 V
Adaptor, On-Machine Distributed Input/Output, 24V DC, PROFIBUS DP
Egenskaper for produkt/familie
- Available with DeviceLogix™ technology
- Powered from the backplane by the communication module or expansion power supply
- Choices include digital, analog, and specialty I/O
| Spesifikasjoner | |
|---|---|
| Communication Adaptor Type | Profibus DP |
| Termination Type | M12 Quick-Disconnect |
| Opprinnelsesland | SG |
| Tolltariffnummer | 85371098 |
| Lengde | 10.5 |
| Høyde | 8.001 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 1738-in015_-en-e.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
Wiring Diagram Filnavn: en-US Filtype: application/x-msmetafile |
Last ned | |
|
Wiring Diagram (DWG) Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
Specification Sheet Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
Dimension Sheet Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABIOT080.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABIOT080.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
ABIOT080.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABIOT080.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned | |
|
ABIOT081.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABIOT081.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
ABIOT081.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABIOT081.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned |
