9 A 100-C Contactor

Produktnummer: 100-C09KF300
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 9A, 3 N.O. 1 N.C. Main Contact Configuration, Single Pack

Contactor, 9 A, 230V 50/60 Hz, AC, 3 NO Poles & 1 NC Pole, 230V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
Spesifikasjoner
Actual Life Actual Life Cannot be Calculated (more information)...
Utilization Category AC-3 Squirrel-cage motor starting and stopping
3-Phase HP (60 Hz) 575V Rating 7.5
1-Phase HP (60 Hz) 230V Rating 1.5
1-Phase HP (60 Hz) 115V Rating 0.5
Connection Screw Terminals
No. of Poles 4 Poles
Terminal Type Screw Terminals
Package Quantity 1
Coil Termination Line Side
Rated Operating Current, AC-3 9A
Contact Configuration 3 N.O. 1 N.C. Main Contact Configuration
Coil Voltage 230V 50/60Hz
Electrical Standards UL
Left Side Auxiliary Contact None
Right Side Auxiliary Contact None
100-C or 104-C Contactor None
Interlock None
Front Mounted Auxiliary Contact None
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 8.407
Høyde 9.804
Livssyklus Active
