3-PORT ENET/IP TAP - 2 TP/1 FIBER

Produktnummer: 1783-ETAP1F
Produktstatus:


inkl. mva.

Networks and Communication Products, EtherNet/IP Tap2 copper ports, 1 fiber port

Embedded Switch Technology – 3-PORT EtherNet/IP TAP - 2 Copper Ports  / 1 FIBER Port

Egenskaper for produkt/familie

  • 140;1585J-M8TBJM-1M9
  • Allows for a high-performance ring capability (make/break < 3 ms), complete with diagnostics and fast recovery to lower downtime
  • Enables greater topology configuration choices for EtherNet/IP applications, such as linear and device-level ring (DLR)
  • Includes embedded Ethernet switch technology in selected components—such as taps and communication interface modules—that communicate over an EtherNet/IP™ network
  • Makes it possible to connect to a linear or ring topology without additional hardware
  • Supports IEEE 1588 precision time protocol (PTP) for precise time synchronization and Quality of Service (QoS) to help prioritize data transmission
Spesifikasjoner
Current Consumption, Max 200mA @ 24VDC
Interface 2 Copper RJ45, 1 Fiber LC Multimode
Power Consumption, Max 4.8 W
Operating Temperature 0...60 °C (32...140 °F)
Power Supply 24 VDC
Data Transfer Rate 2 Copper - 10/100 Mbps, 1 Fiber - 100 Mbps
Enclosure IP20
Type EtherNet/IP Tap
Depth 105mm, 4.13in
Height 132mm, 5.16in
Width 35mm, 1.36in
Sub Brand Stratix
Network Media Male RJ45 to Male RJ45 Patchcord, Unshielded Twisted Pair, Teal TPE Cable, 1.9 m
Ethernet/IP Taps EtherNet/IP Tap2 copper ports, 1 fiber port
Opprinnelsesland US
Tolltariffnummer 85176200
Lengde 16.104
Høyde 11.506
Livssyklus Active
