KONTAKTOR 60A AC3 230V50/60

Produktnummer: 100-C60KF00
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 60A, 0 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack

Contactor, 60 A, 230V 50/60 Hz, AC, 3 Normally Open Poles, 230V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Egenskaper for produkt/familie

  • Provides IP2X finger protection
  • Offers common accessories for all contactor sizes
  • Includes reversible coil terminations (line or load side)
  • Provides reversible coil terminations (line or load side)
  • Includes electronic and pneumatic timing modules
  • Provides front and side mounting of auxiliary contacts
  • Includes space-saving coil-mounted control modules
  • Includes built-in surge suppression with DC coils
  • RoHs compliant
  • Meets IEC, UL, and CSA standards requirements
Spesifikasjoner
Connection Screw Terminals
3-Phase kW (50 Hz) 230V Rating 18.5
3-Phase kW (50 Hz) 400V/415V Rating 32
3-Phase kW (50 Hz) 500V Rating 37
3-Phase kW (50 Hz) 690V Rating 32
1-Phase HP (60 Hz) 230V Rating 10
3-Phase HP (60 Hz) 200V Rating 15
3-Phase HP (60 Hz) 230V Rating 20
3-Phase HP (60 Hz) 460V Rating 40
3-Phase HP (60 Hz) 575V Rating 50
Terminal Type Screw Terminals
Rated Operating Current, AC-3 60A
Coil Voltage 230V 50/60Hz
No. of Poles 3 Poles
Coil Termination Line Side
Contact Configuration 0 N.O. 0 N.C. Auxiliary Contact Configuration
Package Quantity 1
Electrical Standards UL
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Actual Life Actual Life Cannot be Calculated (more information)...
100-C or 104-C Contactor None
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
Right Side Auxiliary Contact None
Interlock None
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 13.31
Høyde 14.402
Livssyklus Active
