KONTAKTOR 43A AC3.24VDC LAV EFFEKT, SPOLE UNDER
Produktnummer: 100-C43UEJ00
Produktstatus:
inkl. mva.
100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Load Side, 43A, 0 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack
Contactor, 43 A, IEC, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open Poles, 24V DC Electronic, No Contact Configuration, Single Pack, Load Side Coil Termination, Screw Terminals, Motor Load
| Spesifikasjoner | |
|---|---|
| Actual Life | Actual Life Cannot be Calculated (more information)... |
| Rated Operating Current, AC-3 | 43A |
| Package Quantity | 1 |
| No. of Poles | 3 Poles |
| Coil Voltage | 24V DC Electronic Coil |
| Terminal Type | Screw Terminals |
| Contact Configuration | 0 N.O. 0 N.C. Auxiliary Contact Configuration |
| Coil Termination | Load Side |
| Interlock | None |
| 100-C or 104-C Contactor | None |
| Left Side Auxiliary Contact | None |
| Right Side Auxiliary Contact | None |
| Front Mounted Auxiliary Contact | None |
| 3-Phase HP (60 Hz) 575V Rating | 30 |
| 3-Phase kW (50 Hz) 690V Rating | 22 |
| 3-Phase kW (50 Hz) 500V Rating | 25 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 22 |
| 3-Phase HP (60 Hz) 200V Rating | 10 |
| 1-Phase HP (60 Hz) 230V Rating | 7.5 |
| 3-Phase kW (50 Hz) 230V Rating | 13 |
| Connection | Screw Terminals |
| 3-Phase HP (60 Hz) 460V Rating | 30 |
| 3-Phase HP (60 Hz) 230V Rating | 15 |
| Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
| Electrical Standards | UL |
| Opprinnelsesland | PL |
| Tolltariffnummer | 85364190 |
| Lengde | 11.811 |
| Høyde | 5.969 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
3D STP (STEP) Model Filnavn: 100-C_FS2_AC_DCE Filtype: application/x-zip-compressed |
Last ned | |
|
Repair Parts List Filnavn: 100C-104C-100LC_Parts%20rp.pdf Filtype: application/pdf |
Last ned | |
|
3D Mechanical Drawing (PDF) Filnavn: A-B.100-C_FS2_U_00_3D.pdf Filtype: application/pdf |
Last ned | |
|
MCS 100-C Contactor Photo Filnavn: 100C_43_Ph.jpg Filtype: image/png |
Last ned | |
|
2D Drawing (DWG/DXF) Filnavn: 100-C_FS2_AC_DCE.dxf Filtype: image/vnd.dxf |
Last ned | |
|
2D Drawing (PDF) Filnavn: 100-C_FS2_AC_DCE.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA110.dwg Filnavn: ABMSA110.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA110.dxf Filnavn: ABMSA110.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA110.pdf Filnavn: ABMSA110.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA110.wmf Filnavn: ABMSA110 Filtype: application/x-msmetafile |
Last ned | |
|
ABMSA111.dwg Filnavn: ABMSA111.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA111.dxf Filnavn: ABMSA111.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA111.pdf Filnavn: ABMSA111.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA111.wmf Filnavn: ABMSA111 Filtype: application/x-msmetafile |
Last ned |
