Series 9000 General Purpose Sensor
Produktnummer: 42GRL-9000
Produktstatus:
inkl. mva.
Series 9000, Photoelectric Sensor, 42G, Transmitted Beam Emitter, Infrared LED, 61 m Sensing Range, 2 m Cable
| Spesifikasjoner | |
|---|---|
| Sensing Mode | Transmitted Beam |
| Operating Voltage / Output Type | 10-264V AC/DC |
| Maximum Sensing Distance | 61m (200ft) |
| Output Energized | Light Source |
| Connection Type | 2m (6.5ft) 300V cable |
| Receiver | Transmitted Beam Receiver is not selected |
| Sensing Range | 61m (200ft) |
| Model Selection Information | Selection for Series 9000 Diagnostic |
| Lengde | 18.001 |
| Høyde | 1.999 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 42g-in003_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
Dimension Drawing (DXF) Filnavn: ABGCA920.dxf Filtype: image/vnd.dxf |
Last ned | |
|
Photo Filnavn: PHEL9KDG_PH.jpg Filtype: image/png |
Last ned | |
|
Dimension Drawing (PDF) Filnavn: ABGCA920.pdf Filtype: application/pdf |
Last ned | |
|
3D STEP Model (STP) Filnavn: Series9000 Filtype: application/x-zip-compressed |
Last ned |
