Rekkeklemme 2.5mm2 skru grå

Produktnummer: 1492-J3
Produktstatus:


inkl. mva.

1492-J IEC Terminal Block, One-Circuit Feed-Through Block, 2.5 mm (# 24 AWG - # 12 AWG), Standard Feedthrough, Gray (Standard),

Terminal Block, Screw Connection, Feed Through, 5.1 x 60 x 39.5mm (0.20 x 2.36 x 1.56 in), 1 Pole, Gray, Pkg. Qty. of 100, VOLTAGERATING UR - 600V AC/DC, CSA - 600V AC/DC, IEC - 800V AC/DC, ATEX 550V AC/DC, MAXIMUM CURRENT RATING UR - 25A, CSA - 20A, I

Egenskaper for produkt/familie

  • Four-sided funnel wire guides
  • Backed-out screws
  • Easy installation or removal from both sides of DIN Rail
  • Wide range of accessories available
  • Compatible with several high visibility snap-in marker cards
  • Self-locking screw type clamp design
  • Copper current bar and tin-plated surface
  • Counter-sinking of clamping screws
  • Tin-plated terminal and zinc chromate steel screws
  • Finger-safe housing
Spesifikasjoner
Special Features Standard Feedthrough
Base Block Style Standard Feed-Through Blocks
Base Block Type One-Circuit Feed-Through Block
Features Standard Feedthrough
Maximum Wire Size & Rating UL: 30-12 AWG (25A @600V AC/DC) CSA: 26-12 AWG (20A @600V AC/DC) IEC: 2.5mm² (24A @800V AC/DC) EEx e II: 2.5mm²/20-14 AWG (21A @ 550V AC/DC)
Color Gray (Standard)
Opprinnelsesland DE
Tolltariffnummer 85369010
Lengde 5.08
Høyde 0.476
Livssyklus Active
