Rekkeklemme 10mm2 skru blå
inkl. mva.
1492-J IEC Terminal Block, One-Circuit Feed-Through Block, 10 mm (# 22 AWG - # 8 AWG), Standard Feedthrough, Blue,
Egenskaper for produkt/familie
- Backed-out screws
- Wide range of accessories available
- Easy installation or removal from both sides of DIN Rail
- Copper current bar and tin-plated surface
- Four-sided funnel wire guides
- Finger-safe housing
- Tin-plated terminal and zinc chromate steel screws
- Counter-sinking of clamping screws
- Self-locking screw type clamp design
- Compatible with several high visibility snap-in marker cards
Spesifikasjoner | |
---|---|
Base Block Style | Standard Feed-Through Blocks |
Special Features | Standard Feedthrough |
Features | Standard Feedthrough |
Maximum Wire Size & Rating | UL: 16-6 AWG (65A @600V AC/DC) CSA: 16-6 AWG (65A @600V AC/DC) IEC: 10mm² (57A @1000V AC/DC) EEx e II: 10mm²/16-8 AWG (50A @ 550V AC/DC) |
Color | Blue |
Base Block Type | One-Circuit Feed-Through Block |
Opprinnelsesland | DE |
Tolltariffnummer | 85369095 |
Lengde | 0.61 |
Høyde | 5.207 |
Livssyklus | Active |
Datablad | ||
---|---|---|
Spec Sheet Filnavn: 1492-td015_-en-p.pdf Filtype: application/pdf |
Last ned |
Nedlastinger | ||
---|---|---|
Specifications Filnavn: 1492_J10_J16_J35_Spec.pdf Filtype: application/pdf |
Last ned | |
3D STEP (STP) Model Filnavn: 1492-j10 Filtype: application/x-zip-compressed |
Last ned | |
Wire Size [AWG] Table Filnavn: 1492_Wire_Size_1.pdf Filtype: application/pdf |
Last ned | |
ABTBM070.dwg Filnavn: ABTBM070.dwg Filtype: image/vnd.dwg |
Last ned | |
ABTBM070.dxf Filnavn: ABTBM070.dxf Filtype: image/vnd.dxf |
Last ned | |
ABTBM070.pdf Filnavn: ABTBM070.pdf Filtype: application/pdf |
Last ned | |
ABTBM070.wmf Filnavn: ABTBM070 Filtype: application/x-msmetafile |
Last ned | |
ABTBM071.dwg Filnavn: ABTBM071.dwg Filtype: image/vnd.dwg |
Last ned | |
ABTBM071.dxf Filnavn: ABTBM071.dxf Filtype: image/vnd.dxf |
Last ned | |
ABTBM071.pdf Filnavn: ABTBM071.pdf Filtype: application/pdf |
Last ned | |
ABTBM071.wmf Filnavn: ABTBM071 Filtype: application/x-msmetafile |
Last ned |
