POINT I/O SSI Encoder Module

Produktnummer: 1734-SSI
Produktstatus:


inkl. mva.

SSI Absolute Encoder Interface

Encoder Input Module, POINT I/O, Absolute Synchronous Serial Interface, 1 Channel , Open Style, DIN Mounted

Egenskaper for produkt/familie

  • Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
  • Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
  • Auto Device Replacement (ADR) reduces downtime
  • Available with conformal coating
  • Modular design lets you independently select the I/O, termination style, and network interface
  • Removable wiring system saves time and money during installation and troubleshooting
  • Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
  • Modules slide together for easy install and uninstall for easier maintenance
  • Configurable modules
  • Mount horizontally or vertically, with no de-rating required
Spesifikasjoner
Sub Brand POINT
Enclosure None (open-style)
Type Encoder Interface Module
Temperature Rating -20...55 °C (-4...131 °F)
Power Supply 24V DC
Mounting Din-rail
Special Features Standard
Application In-Cabinet
Isolation Voltage 50V continuous Tested to withstand 1250V ac for 60 s.
Serial Modules SSI Absolute Encoder Interface
Opprinnelsesland SG
Tolltariffnummer 85389099
Lengde 1.778
Høyde 5.842
Livssyklus Active
