POINT I/O Incremental Encoder Interface

Produktnummer: 1734-IJ
Produktstatus:


inkl. mva.

5 Vdc Incremental Encoder Module

Incremental Encoder Module, POINT I/O, 1 Channel, 5 VDC, Open Style, DIN Mounted

Egenskaper for produkt/familie

  • Removable wiring system saves time and money during installation and troubleshooting
  • Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
  • Configurable modules
  • Auto Device Replacement (ADR) reduces downtime
  • Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
  • Available with conformal coating
  • Modular design lets you independently select the I/O, termination style, and network interface
  • Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
  • Mount horizontally or vertically, with no de-rating required
  • Modules slide together for easy install and uninstall for easier maintenance
Spesifikasjoner
Counter Modules 5 Vdc Incremental Encoder Module
Type Encoder Interface Module
Isolation Voltage 50V. Type tested @ 1100V DC for 60 s, field-side to system
Temperature Rating -20...55 °C (-4...131 °F)
Application In-Cabinet
Power Supply 5V DC
Mounting Din-rail
Enclosure None (open-style)
Signal Range 250kHz, 500kHz, 1MHz
Sub Brand POINT
Special Features Standard
Opprinnelsesland SG
Tolltariffnummer 85389099
Lengde 8.204
Høyde 1.6
Livssyklus Active
