POINT I/O 8 Point Analog Input Module

Produktnummer: 1734-IE8C
Produktstatus:


inkl. mva.

24V Dc 8 Channel High Density Analog Current Input Module

Current Input Module, POINT I/O, Analog, 24V Dc, 8 Channels, Open Style, DINMounted

Egenskaper for produkt/familie

  • Modules slide together for easy install and uninstall for easier maintenance
  • Mount horizontally or vertically, with no de-rating required
  • Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
  • Modular design lets you independently select the I/O, termination style, and network interface
  • Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
  • Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
  • Available with conformal coating
  • Configurable modules
  • Auto Device Replacement (ADR) reduces downtime
  • Removable wiring system saves time and money during installation and troubleshooting
Spesifikasjoner
Analog Input Modules 24V Dc 8 Channel High Density Analog Current Input Module
Sub Brand POINT
Power Supply 24V DC
Temperature Rating -20...55 °C (-4...131 °F)
Mounting Din-rail
Signal Range 4...20mA, 0...20mA
Type Analog Input Module
Application In-Cabinet
Resolution 16 Bits
Input 8 Point
Special Features Standard
Enclosure None (open-style)
Isolation Voltage 50V (continuous), basic insulation type, inputs and field power to system. Type tested at 1500V AC for 60 s. No isolation between individual inputs or inputs to field power
Opprinnelsesland SG
Tolltariffnummer 85389099
Lengde 8.001
Høyde 1.702
Livssyklus Active
