POINT I/O 4 Point Analog Output Module

Produktnummer: 1734-OE4C
Produktstatus:


inkl. mva.

24V Dc 4 Points Analog Current Output Module

Output Module, POINT I/O, Analog, Current, 4 Channels Single Ended, Open Style, DIN Mounted

Egenskaper for produkt/familie

  • Available with conformal coating
  • Auto Device Replacement (ADR) reduces downtime
  • Mount horizontally or vertically, with no de-rating required
  • Configurable modules
  • Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
  • Modules slide together for easy install and uninstall for easier maintenance
  • Removable wiring system saves time and money during installation and troubleshooting
  • Modular design lets you independently select the I/O, termination style, and network interface
  • Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
  • Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
Spesifikasjoner
Analog Output Modules 24V Dc 4 Points Analog Current Output Module
Signal Range 4...20mA, 0...20mA
Application In-Cabinet
Enclosure None (open-style)
Type Analog Output Module
Power Supply 24V DC
Output 4 Point
Temperature Rating -20...55 °C (-4...131 °F)
Special Features Standard
Mounting Din-rail
Sub Brand POINT
Isolation Voltage 50V (continuous), basic insulation type, outputs and field powerto system. Type tested at 1500V AC for 60 s. No isolation between individual outputs or outputs to field power
Resolution 16 Bits
Opprinnelsesland SG
Tolltariffnummer 85389099
Lengde 8.128
Høyde 1.778
Livssyklus Active
