POINT I/O 2 Point RTD Input Module
SKU: 1734-IR2E
Product status:
incl. VAT
24V Dc 2 Channel RTD Input Module
Input Module, POINT I/O, RTD, 2 Channels Single Ended Input, High Resolution, Open Style, DIN Mounted
Properties for product/family
- Available with conformal coating
- Mount horizontally or vertically, with no de-rating required
- Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
- Modules slide together for easy install and uninstall for easier maintenance
- Modular design lets you independently select the I/O, termination style, and network interface
- Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
- Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
- Configurable modules
- Removable wiring system saves time and money during installation and troubleshooting
- Auto Device Replacement (ADR) reduces downtime
- 20;837RTD-N1N14A30P2-D4
| Specifications | |
|---|---|
| Sub Brand | POINT |
| Type | RTD Input Module |
| Special Features | Standard |
| Application | In-Cabinet |
| Power Supply | 5V DC |
| Mounting | Din-rail |
| Enclosure | None (open-style) |
| Temperature Rating | -20...55 °C (-4...131 °F) |
| Input | 2 Point |
| Isolation Voltage | 50V (continuous), Basic Insulation Type, I/O to system. Type tested at 1600V AC for 60 s |
| Signal Range | 0...200 ohms |
| Resolution | 16 Bits |
| Temperature Input Modules | 24V Dc 2 Channel RTD Input Module |
| 837RTD Resistance Thermometer | 837RTD Resistance Thermometer ,Standard, Non-Display, 1/4 NPT Male 30mm, Pt100 [Ohm] ,4-pin DC Micro(M12) Integral QD |
| Opprinnelsesland | SG |
| Tolltariffnummer | 85389099 |
| Lengde | 8.509 |
| Høyde | 1.6 |
| Livssyklus | Active |
