POINT I/O 2 Point RTD Input Module

Produktnummer: 1734-IR2
Produktstatus:


inkl. mva.

24V Dc 2 Channel RTD Input Module

Input Module, POINT I/O, RTD, 2 Channels Single Ended Input, Open Style, DIN Mounted

Egenskaper for produkt/familie

  • Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
  • Auto Device Replacement (ADR) reduces downtime
  • Removable wiring system saves time and money during installation and troubleshooting
  • Modular design lets you independently select the I/O, termination style, and network interface
  • Modules slide together for easy install and uninstall for easier maintenance
  • Mount horizontally or vertically, with no de-rating required
  • Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
  • Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
  • Available with conformal coating
  • Configurable modules
  • 20;837RTD-N1N14A30P2-D4
Spesifikasjoner
Sub Brand POINT
Type RTD Input Module
Special Features Standard
Application In-Cabinet
Power Supply 24V DC
Mounting Din-rail
Enclosure None (open-style)
Temperature Rating -20...55 °C (-4...131 °F)
Input 2 Point
Isolation Voltage 50V (continuous), Basic Insulation Type, I/O to system. Type tested at 1600V AC for 60 s
Signal Range 0...600 ohms
Resolution 16 Bits
Temperature Input Modules 24V Dc 2 Channel RTD Input Module
837RTD Resistance Thermometer 837RTD Resistance Thermometer ,Standard, Non-Display, 1/4 NPT Male 30mm, Pt100 [Ohm] ,4-pin DC Micro(M12) Integral QD
Opprinnelsesland SG
Tolltariffnummer 85389099
Lengde 9.398
Høyde 1.651
Livssyklus Active
