ORDER CODE

IOX-DAIO

Power supply (isolated)

12-24 V DC

Operating temperature

-10 °C to +50 °C

Dimensions W×H×D

23 × 109 × 98 mm

Mounting

Din-rail

Serial baud rate

2400 to 115200

Connectors

4/18
Screw connector

Digital inputs

4

Digital outputs

2

Relay outputs

-

Analog inputs
Voltage 0-10 V DC or Current 0(4)-20 mA
12 bit resolution

2

Analog output
Voltage 0(2)-10 V DC
12 bit resolution

1

RTD inputs 2 or 3 wire
100 ppm/°C Typ. drift

2

RTD Types

PT100/Ni120/
PT1000/Ni1000/
Resistance

Counters
32 bits on the digital inputs

 4

Certifications

CE

Guarantee

3 years
