MicroLogix 4 Point Module

Produktnummer: 1762-IR4
Produktstatus:


inkl. mva.

1762 MicroLogix 1200 System, MicroLogix 4 Point Module

4 Channel, RTD/Resistance Module

Egenskaper for produkt/familie

  • Combination module with 8 inputs and 6 contact outputs
  • Software keying prevents incorrect positioning within the system
  • Thermocouple module with 4 input channels plus a CJC sensor
  • Finger-safe terminal blocks for I/O wiring
  • 8, 16, or 32 inputs or outputs
  • Small footprint reduces panel space
  • Network support includes EtherNet/IP™, DeviceNet™, and DH-485 (local only)
  • Output module with 4 single-ended outputs
  • Combination module with 2 differential inputs and 2 single-ended outputs
  • Integrated high-performance I/O bus
  • Label to record I/O terminal designations
  • AC and DC voltages
  • Input module with 4 differential inputs
  • RTD module with 4 input channels
  • Feature-rich functionality addresses a wide range of applications
  • AC/DC relay output modules
  • Digital, analog, and specialty I/O modules available
Spesifikasjoner
I/O Isolation Isolated
Width 40
Enclosure IP20
Depth 87
Mounting DIN Rail, Panel Mount
I/O Status Indication LED
Special Features Standard
Type Specialty
Temperature Rating 0°C to 55°C (32°F to 131°F)
Input 4 Point, TC
Standard c-UL-us CL1DIV2, CE, C-Tick, KCC
Sub Brand MicroLogix 1200
Height 90
Accessories MicroLogix 4 Point Module
Opprinnelsesland MY
Tolltariffnummer 85389099
Lengde 16.612
Høyde 5.41
Livssyklus Active
