Egenskaper for produkt/familie

• Provides additional programming/HMI port for connectivity to a DF1 full-duplex compatible device (only on MicroLogix™ 1200R controllers)
• Expands up to 136 I/O points
• Contains isolated RS-232/RS-485 combo port for serial and networked communication
• AC/DC relay output modules
• Provides program data security
• Integrated high-performance I/O bus
• Small footprint reduces panel space
• Combination module with 2 differential inputs and 2 single-ended outputs
• 8, 16, or 32 inputs or outputs
• Software keying prevents incorrect positioning within the system
• Compatible with 1762 MicroLogix Expansion I/O modules (up to six modules per controller)
• Input module with 4 differential inputs
• Feature-rich functionality addresses a wide range of applications
• Finger-safe terminal blocks for I/O wiring
• Network support includes EtherNet/IP™, DeviceNet™, and DH-485 (local only)
• Digital, analog, and specialty I/O modules available
• AC and DC voltages
• Thermocouple module with 4 input channels plus a CJC sensor
• Includes built-in independent 20 kHz high-speed counter
• Combination module with 8 inputs and 6 contact outputs
• Output module with 4 single-ended outputs
• Provides four latching or pulse-catch inputs and four interrupt inputs
• Supports floating point data files
• Label to record I/O terminal designations
• Offers Programmable Limit Switch function
• RTD module with 4 input channels
• Includes two built-in 3/4-turn trim potentiometers with a digital output range of 0...250
