| Spesifikasjoner | |
|---|---|
| Sensitivity Adjustment | Yes |
| Maximum Sensing Distance | 70mm (2.8in) |
| View | Side |
| Connection Type | 3-pin Pico QD on 152 mm (6 inch) pigtail |
| Light Source | Infrared LED |
| Output Type | Sink (NPN) |
| Sensing Mode | Standard Diffuse |
| Operating Voltage/Mode | 12-24V DC - LO or DO selectable |
| Nedlastinger | ||
|---|---|---|
|
Dimension Drawing (DWG/DXF) Filnavn: 42KB.dwg Filtype: image/vnd.dwg |
Last ned | |
|
3D STEP Model (STP) Filnavn: 42kb_side_view Filtype: application/x-zip-compressed |
Last ned | |
|
Photo Filnavn: PHEL42KB_PH.jpg Filtype: image/png |
Last ned | |
|
ABGCM500.dwg Filnavn: ABGCM500.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABGCM500.dxf Filnavn: ABGCM500.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABGCM500.pdf Filnavn: ABGCM500.pdf Filtype: application/pdf |
Last ned | |
|
ABGCM500.wmf Filnavn: ABGCM500 Filtype: application/x-msmetafile |
Last ned | |
|
ABGCM501.dwg Filnavn: ABGCM501.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABGCM501.dxf Filnavn: ABGCM501.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABGCM501.pdf Filnavn: ABGCM501.pdf Filtype: application/pdf |
Last ned | |
|
ABGCM501.wmf Filnavn: ABGCM501 Filtype: application/x-msmetafile |
Last ned |
