KONTAKTOR 23A AC-3 2NO+2NC POLER 230VAC

Produktnummer: 100-C23KF200
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 23A, 2 N.O. 2 N.C. Main Contact Configuration, Single Pack

Contactor, 23 A, 230V 50/60 Hz, AC, 2 NO Poles & 2 NC Poles, 230V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
Spesifikasjoner
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Electrical Standards UL
100-C or 104-C Contactor None
Interlock None
Right Side Auxiliary Contact None
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
Coil Voltage 230V 50/60Hz
Contact Configuration 2 N.O. 2 N.C. Main Contact Configuration
Coil Termination Line Side
Package Quantity 1
No. of Poles 4 Poles
Rated Operating Current, AC-3 23A
Terminal Type Screw Terminals
Actual Life Actual Life Cannot be Calculated (more information)...
3-Phase kW (50 Hz) 500V Rating 13
3-Phase kW (50 Hz) 690V Rating 10
3-Phase kW (50 Hz) 400V/415V Rating 11
3-Phase HP (60 Hz) 575V Rating 15
3-Phase HP (60 Hz) 230V Rating 7.5
3-Phase HP (60 Hz) 460V Rating 15
3-Phase kW (50 Hz) 230V Rating 7.5
Connection Screw Terminals
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 8.509
Høyde 9.5
Livssyklus Active
