KONTAKTOR 43A AC3 24V50/60

Produktnummer: 100-C43KJ00
Produktstatus:


inkl. mva.

100-C IEC Contactor, 24V 50/60Hz, Screw Terminals, Line Side, 43A, 0 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack

100-C IEC Contactor, 24V 50/60Hz, Screw Terminals, Line Side, 43A, 0 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack

Egenskaper for produkt/familie

  • Includes built-in surge suppression
  • Includes reversible coil terminations (line or load side)
  • Meets IEC, UL, and CSA standards requirements
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • RoHs compliant
  • Provides front and side mounting of auxiliary contacts
  • Provides IP2X finger protection
  • Provides reversible coil terminations (line or load side)
  • Offers common accessories for all contactor sizes
  • Includes electronic and pneumatic timing modules
  • Includes space-saving coil-mounted control modules
Spesifikasjoner
Electrical Standards UL
1-Phase HP (60 Hz) 230V Rating 7.5
3-Phase kW (50 Hz) 230V Rating 13
3-Phase HP (60 Hz) 200V Rating 10
3-Phase HP (60 Hz) 460V Rating 30
3-Phase HP (60 Hz) 575V Rating 30
3-Phase kW (50 Hz) 400V/415V Rating 22
3-Phase kW (50 Hz) 690V Rating 22
3-Phase kW (50 Hz) 500V Rating 25
3-Phase HP (60 Hz) 230V Rating 15
Connection Screw Terminals
Utilization Category AC-3 Squirrel-cage motor starting and stopping
100-C or 104-C Contactor None
Interlock None
Right Side Auxiliary Contact None
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
Actual Life Actual Life Cannot be Calculated (more information)...
No. of Poles 3 Poles
Rated Operating Current, AC-3 43A
Coil Voltage 24V 50/60Hz
Package Quantity 1
Terminal Type Screw Terminals
Contact Configuration 0 N.O. 0 N.C. Auxiliary Contact Configuration
Coil Termination Line Side
Opprinnelsesland PL
Tolltariffnummer 85364190
Lengde 8.71
Høyde 5.89
Livssyklus Active
