KONTAKTOR 4-POL 9A AC-3. 230VAC

Produktnummer: 100-C09KF400
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 9A, 4 N.O. 0 N.C. Main Contact Configuration, Single Pack

Contactor, 9 A, 230V 50/60 Hz, AC, 4 Normally Open Poles, 230V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Egenskaper for produkt/familie

  • Includes electronic and pneumatic timing modules
  • Offers common accessories for all contactor sizes
  • Includes built-in surge suppression
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Provides reversible coil terminations (line or load side)
  • RoHs compliant
  • Includes space-saving coil-mounted control modules
  • Provides front and side mounting of auxiliary contacts
  • Includes reversible coil terminations (line or load side)
  • Provides IP2X finger protection
  • Meets IEC, UL, and CSA standards requirements
Spesifikasjoner
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Actual Life Actual Life Cannot be Calculated (more information)...
3-Phase HP (60 Hz) 575V Rating 7.5
1-Phase HP (60 Hz) 115V Rating 0.5
Connection Screw Terminals
1-Phase HP (60 Hz) 230V Rating 1.5
Left Side Auxiliary Contact None
Right Side Auxiliary Contact None
100-C or 104-C Contactor None
Interlock None
Front Mounted Auxiliary Contact None
Electrical Standards UL
No. of Poles 4 Poles
Package Quantity 1
Contact Configuration 4 N.O. 0 N.C. Main Contact Configuration
Coil Voltage 230V 50/60Hz
Rated Operating Current, AC-3 9A
Terminal Type Screw Terminals
Coil Termination Line Side
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 2.49
Høyde 10.8
Livssyklus Active
