KONTAKTOR 30A AC3.24VDC LAV EFFEKT

Produktnummer: 100-C30EJ00
Produktstatus:


inkl. mva.

Contactor, 30 A, IEC, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open Poles, 24V DC Electronic, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Egenskaper for produkt/familie

  • Provides IP2X finger protection
  • Provides reversible coil terminations (line or load side)
  • RoHs compliant
  • Includes reversible coil terminations (line or load side)
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Offers common accessories for all contactor sizes
  • Meets IEC, UL, and CSA standards requirements
  • Includes electronic and pneumatic timing modules
  • Includes built-in surge suppression
  • Includes space-saving coil-mounted control modules
  • Provides front and side mounting of auxiliary contacts
Spesifikasjoner
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Actual Life Actual Life Cannot be Calculated (more information)...
Coil Termination Line Side
No. of Poles 3 Poles
Rated Operating Current, AC-3 30A
Package Quantity 1
Coil Voltage 24V DC Electronic Coil
Contact Configuration 0 N.O. 0 N.C. Auxiliary Contact Configuration
Terminal Type Screw Terminals
Electrical Standards UL
100-C or 104-C Contactor None
Interlock None
Right Side Auxiliary Contact None
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
3-Phase kW (50 Hz) 690V Rating 15
3-Phase HP (60 Hz) 575V Rating 25
Connection Screw Terminals
3-Phase HP (60 Hz) 230V Rating 10
3-Phase HP (60 Hz) 460V Rating 20
3-Phase kW (50 Hz) 230V Rating 10
3-Phase kW (50 Hz) 500V Rating 15
3-Phase kW (50 Hz) 400V/415V Rating 15
3-Phase HP (60 Hz) 200V Rating 7.5
Lengde 11.506
Høyde 4.902
Livssyklus Active
