Kontaktor 146A, 100-250VAC/DC styresp. PLC interf. 1NO/1NC
Produktnummer: 100-E146ED11
Produktstatus:
inkl. mva.
100-E MCS-E Contactor ,146A, AC3 duty , 100-250V 50/60Hz / 100-250V DC Electronic Coil w/ PLC Interface , 1 N.O. 1 N.C.
Contactor, IEC, 146 A, 100-250V 50-60 Hz/100-250V DC, 3 NO Poles, 1 NO 1 NC Auxiliary Contacts, With 24V DC PLC Interface, Bus BarConnections
Egenskaper for produkt/familie
- Includes built-in surge suppression
- Simplifies selection with electronic wide-range AC/DC coils
- Complies with RoHs
- Meets IEC, UL, and CSA standards requirements
- Saves energy with low power consumption
- Available integrated PLC interface
| Spesifikasjoner | |
|---|---|
| Phases | Three Phase |
| Contactor Type | 100-E MCS-E Contactor |
| Contactor Size | 146A, AC3 duty |
| Coil Type | Electronic Coil w/ PLC Interface |
| Control Voltage | 100-250V AC 50/60Hz / 100-250V DC Electronic Coil w/ PLC Interface |
| Auxiliary Contact Configuration | 1 N.O. 1 N.C. |
| Terminal Type | Bar Connections |
| Lengde | 21.336 |
| Høyde | 14.986 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
Technical Detail Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
3-Dimensional STEP model (STP) Filnavn: en-US Filtype: application/x-zip-compressed |
Last ned | |
|
2-Dimensional Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
Photo Filnavn: en-US Filtype: image/png |
Last ned |
