KONTAKTOR 12A AC3 230V50/60

Produktnummer: 100-C12KF01
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 12A, 0 N.O. 1 N.C. Auxiliary Contact Configuration, Single Pack

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 12A, 0 N.O. 1 N.C. Auxiliary Contact Configuration, Single Pack

Egenskaper for produkt/familie

  • Provides front and side mounting of auxiliary contacts
  • Includes space-saving coil-mounted control modules
  • RoHs compliant
  • Provides IP2X finger protection
  • Offers common accessories for all contactor sizes
  • Provides reversible coil terminations (line or load side)
  • Includes electronic and pneumatic timing modules
  • Includes built-in surge suppression
  • Includes reversible coil terminations (line or load side)
  • Meets IEC, UL, and CSA standards requirements
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
Spesifikasjoner
3-Phase kW (50 Hz) 690V Rating 5.5
3-Phase HP (60 Hz) 575V Rating 10
3-Phase kW (50 Hz) 500V Rating 5.5
3-Phase HP (60 Hz) 460V Rating 7.5
Connection Screw Terminals
1-Phase HP (60 Hz) 115V Rating 0.5
3-Phase kW (50 Hz) 400V/415V Rating 5.5
100-C or 104-C Contactor 2_
Left Side Auxiliary Contact None
Front Mounted Auxiliary Contact None
Right Side Auxiliary Contact None
Interlock None
Contact Configuration 0 N.O. 1 N.C. Auxiliary Contact Configuration
Terminal Type Screw Terminals
Coil Termination Line Side
Package Quantity 1
Coil Voltage 230V 50/60Hz
Rated Operating Current, AC-3 12A
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Electrical Standards UL
Actual Life Actual Life Cannot be Calculated (more information)...
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 2.49
Høyde 10.8
Livssyklus Active
