fjærklemme 6mm2

Produktnummer: 1492-L6
Produktstatus:


inkl. mva.

Spring Clamp Terminal Block,One-Circuit Feed-Through Block,6 mm (# 22 AWG - # 10 AWG), 4 mm for H4 block,Standard Feedthrough,Gray (Standard),

Terminal Block, Spring Clamp Connection, Feed Through, 8.1 x 65 x 38mm (0.319 x 2.56 x 1.5 in), 1 Pole, Gray, Pkg. Qty. of 50, VOLTAGE RATING UR - 600V AC/DC, CSA - 600V AC/DC, IEC - 800V AC/DC, ATEX - 550V AC/DC, MAXIMUM CURRENT RATING UR - 50A, CSA -

Egenskaper for produkt/familie

  • Secure contact is durable under extreme conditions
  • Screwless termination technology
  • Requires only a flat-head screwdriver for installation
  • Helps reduce wiring time by more than 50%
  • Maintenance-free, no need to retighten
  • Wide range of accessories available
Spesifikasjoner
Special Features Standard Feedthrough
Hazardous Location No
Base Block Style Standard Feed-Through Blocks
Base Block Type One-Circuit Feed-Through Block
Features Standard Feedthrough
Maximum Wire Size & Rating UL: 22-8 AWG (50A @600V AC/DC) CSA: 20-8 AWG (50A @600V AC/DC) IEC: 6mm² (41A @800V AC/DC) EEx e II: 6mm²/20-8 AWG (36A @550V AC/DC)
Color Gray (Standard)
Opprinnelsesland CZ
Tolltariffnummer 85369010
Lengde 0.406
Høyde 5.004
Livssyklus Active
