fjærklemme 2.5mm2 grå

Produktnummer: 1492-L3
Produktstatus:


inkl. mva.

Spring Clamp Terminal Block,One-Circuit Feed-Through Block,2.5mm² (# 30 AWG - # 12 AWG),Standard Feedthrough,Gray (Standard),

Terminal Block, Spring Clamp Connection, Feed Through, 5.1 x 59.5 x 31.3mm (0.20 x 2.34 x 1.23 in), 1 Pole, Gray, Pkg. Qty. of100, VOLTAGE RATING UR - 600V AC/DC, CSA - 600V AC/DC, IEC - 800V AC/DC, ATEX - 550V AC/DC, MAXIMUM CURRENT RATING UR - 25A,

Egenskaper for produkt/familie

  • Maintenance-free, no need to retighten
  • Secure contact is durable under extreme conditions
  • Wide range of accessories available
  • Screwless termination technology
  • Requires only a flat-head screwdriver for installation
  • Helps reduce wiring time by more than 50%
Spesifikasjoner
Special Features Standard Feedthrough
Hazardous Location No
Base Block Style Standard Feed-Through Blocks
Base Block Type One-Circuit Feed-Through Block
Features Standard Feedthrough
Maximum Wire Size & Rating UL: 30-12 AWG (25A @600V AC/DC) CSA: 26-12 AWG (27A @600V AC/DC) IEC: 2.5mm² (24A @800V AC/DC) EEx e II: 2.5mm²/20-12 AWG (21A @550V AC/DC)
Color Gray (Standard)
Opprinnelsesland CZ
Tolltariffnummer 85369010
Lengde 0.203
Høyde 4.597
Livssyklus Active
