fjærklemme 2.5mm2 blå
Produktnummer: 1492-L3-B
Produktstatus:
inkl. mva.
Spring Clamp Terminal Block,One-Circuit Feed-Through Block,2.5mm² (# 30 AWG - # 12 AWG),Standard Feedthrough,Blue,
Terminal Block, Spring Clamp Connection, Feed Through, 5.1 x 59.5 x 31.3mm (0.20 x 2.34 x 1.23 in), 1 Pole, Blue, Pkg. Qty. of100, VOLTAGE RATING UR - 600V AC/DC, CSA - 600V AC/DC, IEC - 800V AC/DC, ATEX - 550V AC/DC, MAXIMUM CURRENT RATING UR - 25A,
Egenskaper for produkt/familie
- Screwless termination technology
- Wide range of accessories available
- Maintenance-free, no need to retighten
- Helps reduce wiring time by more than 50%
- Requires only a flat-head screwdriver for installation
- Secure contact is durable under extreme conditions
| Spesifikasjoner | |
|---|---|
| Special Features | Standard Feedthrough |
| Hazardous Location | No |
| Base Block Style | Standard Feed-Through Blocks |
| Base Block Type | One-Circuit Feed-Through Block |
| Features | Standard Feedthrough |
| Maximum Wire Size & Rating | UL: 30-12 AWG (25A @600V AC/DC) CSA: 26-12 AWG (27A @600V AC/DC) IEC: 2.5mm² (24A @800V AC/DC) EEx e II: 2.5mm²/20-12 AWG (21A @550V AC/DC) |
| Color | Blue |
| Opprinnelsesland | CZ |
| Tolltariffnummer | 85369010 |
| Lengde | 0.05 |
| Høyde | 13.0 |
| Livssyklus | Active |
