fjærklemme 10mm2

Produktnummer: 1492-L10
Produktstatus:


inkl. mva.

Spring Clamp Terminal Block,One-Circuit Feed-Through Block,10 mm (# 22 AWG - # 8 AWG),Standard Feedthrough,Gray (Standard),

Terminal Block, Spring Clamp Connection, Feed Through, 10 x 73.5 x 43.5mm (0.394 x 2.89 x 1.71 in), 1 Pole, Gray, Pkg. Qty. of 25, VOLTAGE RATING UR - 600V AC/DC, CSA - 600V AC/DC, IEC - 800V AC/DC, ATEX - 550V AC/DC, MAXIMUM CURRENT RATING UR - 60A, C

Egenskaper for produkt/familie

  • Secure contact is durable under extreme conditions
  • Wide range of accessories available
  • Requires only a flat-head screwdriver for installation
  • Helps reduce wiring time by more than 50%
  • Screwless termination technology
  • Maintenance-free, no need to retighten
Spesifikasjoner
Maximum Wire Size & Rating UL: 16-6 AWG (60A @600V AC/DC) CSA: 16-6 AWG (55A @600V AC/DC) IEC: 10mm² (57A @800V AC/DC) EEx e II: 10mm²/16-8 AWG (50A @550V AC/DC)
Color Gray (Standard)
Features Standard Feedthrough
Special Features Standard Feedthrough
Base Block Type One-Circuit Feed-Through Block
Base Block Style Standard Feed-Through Blocks
Hazardous Location No
Opprinnelsesland RO
Tolltariffnummer 85369010
Lengde 0.787
Høyde 5.791
Livssyklus Active
