fjærklemme 1,5mm2 1+2 løp grå

Produktnummer: 1492-L2T
Produktstatus:


inkl. mva.

Spring Clamp Terminal Block,One-Circuit Feed-Through Block,1.5mm² (# 26 AWG - # 14 AWG),2 Connection points on one side,Gray (Standard),

Terminal Block, Spring Clamp Connection, Feed Through with 2 Connection Points on One Side, 3.5 x 63 x 29.5mm (0.138 x 2.48 x 1.16in), 1 Pole, Gray, Pkg. Qty. of 50, VOLTAGE RATING UR - 300V AC/DC, CSA - 300V AC/DC, IEC - 500V AC/DC, ATEX - 550V AC/DC,

Egenskaper for produkt/familie

  • Maintenance-free, no need to retighten
  • Requires only a flat-head screwdriver for installation
  • Helps reduce wiring time by more than 50%
  • Screwless termination technology
  • Wide range of accessories available
  • Secure contact is durable under extreme conditions
Spesifikasjoner
Special Features 2 Connection points on one side
Hazardous Location No
Base Block Style Standard Feed-Through Blocks
Base Block Type One-Circuit Feed-Through Block
Features 2 Connection points on one side
Maximum Wire Size & Rating UL: 26-14 AWG (15A @300V AC/DC) CSA: 26-14 AWG (20A @300V AC/DC) IEC: 1.5mm² (17.5A @500V AC/DC) EEx e II: 1.5mm² (15A @550V AC/DC)
Color Gray (Standard)
Opprinnelsesland CZ
Tolltariffnummer 85369010
Lengde 0.305
Høyde 4.089
Livssyklus Active
