Effektbryter 70A Frame G Mtr-Ckt Protector, Icu=65KA-480V
inkl. mva.
140MG - Motor Circuit Protectors, G frame, 35..65 kA at 480V, MCP (magnetic only), Rated Current 70 A
Egenskaper for produkt/familie
- Includes visible trip indication
- Offers high current limiting option
- Offers high switching capacity
Spesifikasjoner | |
---|---|
Bulletin Number | 140MG - Motor Circuit Protectors |
Protection Type | MCP (magnetic only) |
Frame Size | G frame |
Rated Operational Current Ie(A) | 70 A |
Assembly | Factory Assembled |
Opprinnelsesland | IT |
Tolltariffnummer | 85362090 |
Lengde | 13.59 |
Høyde | 12.9 |
Livssyklus | Active |
Datablad | ||
---|---|---|
Spec Sheet Filnavn: 140g-sg001_-en-p.pdf Filtype: application/pdf |
Last ned |
Nedlastinger | ||
---|---|---|
2-Dimensional Drawing (DWG/DXF) Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
Link to Literature Library for Selectivity Guide Filnavn: en-US Filtype: application/pdf |
Last ned | |
Link to Literature Library for Installation Instructions Filnavn: en-US Filtype: application/pdf |
Last ned | |
Link to Literature Library for Tech Data Filnavn: en-US Filtype: application/pdf |
Last ned | |
Photo Filnavn: en-US Filtype: image/png |
Last ned | |
3-Dimensional STEP model (STP) Filnavn: en-US Filtype: application/x-zip-compressed |
Last ned | |
2-Dimensional Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned |
