Effektbr.4-pol G str. 63A Icu=36KA 400V fast.term./magn.

Produktnummer: 140G-G2C4-C63

inkl. mva.

140G - Molded Case Circuit Breaker, G frame, 25 kA, T/M - Thermal Magnetic, 4 Poles, Rated Current 63 A

Molded Case Circuit Breaker, G frame, 25 kA at 480V, T/M - Fixed Thermal / Fixed Magnetic TMF, Rated Current 63 A, 4 Pole, Interrupting Code G2

Egenskaper for produkt/familie

  • Provides greater customization in trip units
  • Offers a wide range of operating mechanisms to fit a variety of panel configurations
  • Approved for global application: UL, CSA, CCC, and IEC performance interrupting/breaking capacity
  • Offers a wide range of accessories for global availability
60 Frame/Rating
110 Breaking Capacity, 50/60 Hz, 415V (kA)
100 Breaking Capacity, 50/60 Hz, 220V (kA)
80 Interrupting Rating, 50/60 Hz, 480V (kA)
120 Breaking Capacity, 50/60 Hz, 440V (kA)
90 Interrupting Rating, 50/60 Hz, 600V (kA)
70 Interrupting Rating, 50/60 Hz, 240V (kA)
20 Frame Size
40 Protection
30 Rated Current(A)
0 Device Type
10 Number of Poles
50 Assembly
Opprinnelsesland IT
Tolltariffnummer 85362090
Lengde 14.0
Høyde 13.0
Livssyklus Active
