Effektbr.3-pol G 35A 36KA 400V fast.t/m. 1c/o 250V
Produktnummer: 140G-G2C3-C35-KA
Produktstatus:
inkl. mva.
Molded Case Ckt-BKR, 125A G Frame, 25 kA at 480V, T/M - Fixed Thrm / Fixed Mgntc, 3 Poles, 35A, 80 Percent MCCB, No Bus Bar Mounting, NONE, 250V AC/DC, NONE, Aux
| Spesifikasjoner | |
|---|---|
| Device Type | 140G - Molded Case Circuit Breaker |
| Number of Poles | 3 Poles |
| Frame Size | G frame |
| Rated Current(A) | 35 A |
| Protection | T/M - Thermal Magnetic |
| Assembly | Factory Assembled |
| Auxiliary and Alarm Contacts | 1 NO/NC AUX, 250V |
| Lengde | 14.859 |
| Høyde | 13.081 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 140g-sg001_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
3-Dimensional STEP model (STP) Filnavn: en-US Filtype: application/x-zip-compressed |
Last ned | |
|
2-Dimensional Drawing (DWG/DXF) Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
Link to Literature Library for Tech Data Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
Link to Literature Library for Installation Instructions Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
Photo Filnavn: en-US Filtype: image/png |
Last ned | |
|
Link to Literature Library for Selectivity Guide Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
2-Dimensional Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned |
