Effektbr.4-pol G str. 30A Icu=36KA 400V fast.term./magn.

Produktnummer: 140G-G2C4-C25
Produktstatus:


inkl. mva.

140G - Molded Case Circuit Breaker, G frame, 25 kA, T/M - Thermal Magnetic, 4 Poles, Rated Current 25 A

Molded Case Circuit Breaker, G frame, 25 kA at 480V, T/M - Fixed Thermal / Fixed Magnetic TMF, Rated Current 25 A, 4 Pole, Interrupting Code G2

Egenskaper for produkt/familie

  • Approved for global application: UL, CSA, CCC, and IEC performance interrupting/breaking capacity
  • Provides greater customization in trip units
  • Offers a wide range of accessories for global availability
  • Offers a wide range of operating mechanisms to fit a variety of panel configurations
Spesifikasjoner
Assembly Factory Assembled
Breaking Capacity, 50/60 Hz, 440V (kA) 36
Breaking Capacity, 50/60 Hz, 415V (kA) 36
Interrupting Rating, 50/60 Hz, 240V (kA) 50
Interrupting Rating, 50/60 Hz, 480V (kA) 25
Interrupting Rating, 50/60 Hz, 600V (kA) 10
Breaking Capacity, 50/60 Hz, 220V (kA) 65
Bulletin Number 140G - Molded Case Circuit Breaker
Frame/Rating G Frame (125 A)
Rated Current(A) 25 A
Protection T/M - Thermal Magnetic
Frame Size G frame
Number of Poles 4 Poles
Device Type 140G - Molded Case Circuit Breaker
Opprinnelsesland IT
Tolltariffnummer 85362010
Lengde 14.0
Høyde 13.0
Livssyklus Active
