Effektbr.3-pol J str.300A Icu=70KA 400V just.term./magn.

Produktnummer: 140G-K6F3-D30
Produktstatus:


inkl. mva.

140G - Molded Case Circuit Breaker, K frame, 65 kA, T/M - Thermal Magnetic, 3 Poles, Rated Current 300 A (80% Rated)

Molded Case Ckt-BKR, 400A K Frame, 65 kA at 480V, T/M - Adjst Thrm / Adjst Mgntc, 3 Poles, 300A, 80 Percent MCCB, No Bus Bar Mounting, NONE, None, NONE, None

Egenskaper for produkt/familie

  • Offers a wide range of accessories for global availability
  • Offers a wide range of operating mechanisms to fit a variety of panel configurations
  • Approved for global application: UL, CSA, CCC, and IEC performance interrupting/breaking capacity
  • Provides greater customization in trip units
Spesifikasjoner
Bulletin Number 140G - Molded Case Circuit Breaker
Frame/Rating K Frame (400 A)
Interrupting Rating, 50/60 Hz, 240V (kA) 150
Interrupting Rating, 50/60 Hz, 480V (kA) 65
Interrupting Rating, 50/60 Hz, 600V (kA) 35
Breaking Capacity, 50/60 Hz, 220V (kA) 100
Breaking Capacity, 50/60 Hz, 415V (kA) 70
Breaking Capacity, 50/60 Hz, 440V (kA) 65
Breaking Capacity, 50/60 Hz, 690V (kA) 40
Interrupting Rating, 50/60 Hz, 500V DC (kA) 50
Interrupting Rating, 50/60 Hz, 600V DC (kA) 35
Device Type 140G - Molded Case Circuit Breaker
Number of Poles 3 Poles
Frame Size K frame
Rated Current(A) 300 A
Protection T/M - Thermal Magnetic
Current Range 80% Rated
Assembly Factory Assembled
Opprinnelsesland IT
Tolltariffnummer 85362090
Lengde 30.099
Høyde 23.813
Livssyklus Active
