CompactLogix 32 Point 24VDC Input Module

Produktnummer: 1769-IQ32
Produktstatus:


inkl. mva.

32 Point 24VDC Input Module

Input Module, CompactLogix, DC Digital, 32 Point 10-30V DC, 32 Sinking or Sourcing Input

Egenskaper for produkt/familie

  • Integrates with 1769 Compact I/O™ modules
  • Include over-range and under-range detection and indication
  • Include I/O packet rate of 10,000 pps
  • Includes up to a 2-GB secure digital (SD) card for fast program save and restore
  • Provide optical isolation
  • Available with conformal coating
  • Provide dual Ethernet ports for both DLR and linear topologies
  • Delivers standard, safety and motion control for On-Machine™ applications
  • Provide high accuracy ratings
  • Connects as many as three banks of Compact I/O™ to a controller; requires use of a communication adapter module and power supply
  • Provides integrated safety and integrated motion in a single controller
  • Lets you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet (select models only)
  • Offers a smaller form factor for maximized cabinet space
  • Offer user memory options ranging 2 MB to 3 MB
  • Include ability to direct output device operation during an abnormal condition
  • Ideal for small, to mid-size applications that require low axis motion and I/O point counts
  • Provides ability to connect with scaled HMI options from the PanelView™ Plus portfolio to PanelView 800 graphic terminals for simple features
  • Offer a variety of AC and DC voltages
  • Let you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet
  • Direct 1769 platform connection to PowerFlex® drives and other devices through Compact I/O™ to DPI/SCANport™ and Compact I/O to DSI/Modbus modules
  • Removes the need for lithium batteries with built-in energy storage
  • Include on-board scaling
  • Address reserve, ASCII, Boolean control, and high-speed counter modules available
  • Allow control migrations with re-use of existing 1769 I/O
  • Offer selectable response to a broken input sensor
  • Require SERCOS interface modules for motion
  • Does not require a chassis
  • Supports integrated safety up to SIL 3, PLe CAT 4
  • Includes individual point diagnostic status indicators to ease troubleshooting
  • Provides seamless bridging with data control and collection over the same network
  • Offer input filtering
  • Includes a 1769-SDN communication interface module for I/O control and remote device configuration over DeviceNet
  • Include 8…32 points per module
  • Require a chassis
  • Offers support for Integrated Motion over EtherNet/IP™ for maximized scalability
  • Integrate with 1769 Compact I/O™ modules
  • Offers flexible user memory options
  • Include high speed input modules
  • Support single network strategy to EtherNet/IP TCP/CIP connection 96
  • Support seamless bridging with data control and collection over the same network
  • Support SIL 3, PLe integrity (L4xS controllers only)
  • Provide integrated serial port
  • Include autocalibration of inputs
  • Provides up to 16 axes of Integrated Motion over EtherNet/IP
  • Permit on-line editing, forcing and other standard activities while securely isolating safety functionality (L4xS controllers only)
  • Simplify your system architecture with distributed I/O over EtherNet/IP
  • Offers built-in communication ports for EtherNet/IP or ControlNet networks
  • Provides support for Device Level Ring (DLR) network topologies to help increase network resiliency
  • Provides flexibility with DIN rail or panel mounting options
  • Include contact output modules
  • Offer analog, thermocouple, and RTD modules
  • Provide individually configurable channels
  • Includes a built-in RS-232 serial port on every 1769-L3x controller
  • Prevents incorrect positioning of module with software keying
  • Supports up to 2 axes Kinematics for simple articulated robotics
  • Offer direct connection
  • Offers open socket capability that allows support for Modbus TCP as well as devices such as printers, barcode readers and servers
Spesifikasjoner
Sub Brand CompactLogix
Type Digital Input
Special Features Sink or Sourcing Input
Isolation 1200V AC for 1 s or 1697V DC for 1 s, input point to bus and group to group. 75V DC working voltage (IEC Class 2 reinforced insulation)
Enclosure None (open-style)
Display Status LEDs
Mounting DIN Rail / Panel mount
Height 118mm, 4.65"
Width 35mm, 1.38"
Depth 87mm, 3.43"
Operating Temperature 0...60 °C (32...140 °F)
Number Of Channels 32
Input Signal 10...30V DC
Removable Terminal Block 1769-RTBN18 (1 per kit)
Replacement Door Label 1769-RL1 (2 per kit)
Replacement Door 1769-RD (2 per kit)
Digital Input Modules 32 Point 24VDC Input Module
Opprinnelsesland MY
Tolltariffnummer 85389099
Lengde 16.104
Høyde 6.909
Livssyklus Active
