0 100-C Contactor
Produktnummer: 100-C12KJ400
Produktstatus:
inkl. mva.
100-C IEC Contactor, 24V 50/60Hz, Screw Terminals, Line Side, 12A, 4 N.O. 0 N.C. Main Contact Configuration, Single Pack
Contactor, 12 A, 24V 50/60 Hz, AC, 4 Normally Open Poles, 24V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
| Spesifikasjoner | |
|---|---|
| Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
| Rated Operating Current, AC-3 | 12A |
| Package Quantity | 1 |
| No. of Poles | 4 Poles |
| Contact Configuration | 4 N.O. 0 N.C. Main Contact Configuration |
| Coil Termination | Line Side |
| Terminal Type | Screw Terminals |
| Coil Voltage | 24V 50/60Hz |
| 1-Phase HP (60 Hz) 115V Rating | 0.5 |
| Connection | Screw Terminals |
| 3-Phase kW (50 Hz) 690V Rating | 5.5 |
| 3-Phase HP (60 Hz) 575V Rating | 10 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 5.5 |
| 3-Phase kW (50 Hz) 500V Rating | 5.5 |
| 3-Phase HP (60 Hz) 460V Rating | 7.5 |
| Actual Life | Actual Life Cannot be Calculated (more information)... |
| 100-C or 104-C Contactor | None |
| Right Side Auxiliary Contact | None |
| Interlock | None |
| Front Mounted Auxiliary Contact | None |
| Left Side Auxiliary Contact | None |
| Electrical Standards | UL |
| Opprinnelsesland | CH |
| Tolltariffnummer | 85364190 |
| Lengde | 8.999 |
| Høyde | 5.001 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
MCS 100-C Contactor Photo Filnavn: 100C_23_Ph.jpg Filtype: image/png |
Last ned | |
|
3D Mechanical Drawing (PDF) Filnavn: A-B.100-C_FS0_400_3D.pdf Filtype: application/pdf |
Last ned | |
|
3D STP (STEP) Model Filnavn: 100-C_FS0_AC_DCE Filtype: application/x-zip-compressed |
Last ned | |
|
Repair Parts List Filnavn: 100C-104C-100LC_Parts%20rp.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA190.dwg Filnavn: ABMSA190.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA190.dxf Filnavn: ABMSA190.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA190.pdf Filnavn: ABMSA190.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA190.wmf Filnavn: ABMSA190 Filtype: application/x-msmetafile |
Last ned | |
|
ABMSA191.dwg Filnavn: ABMSA191.dwg Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA191.dxf Filnavn: ABMSA191.dxf Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA191.pdf Filnavn: ABMSA191.pdf Filtype: application/pdf |
Last ned | |
|
ABMSA191.wmf Filnavn: ABMSA191 Filtype: application/x-msmetafile |
Last ned |
