IEC 16 A Contactor

Produktnummer: 100-C16EJ01
Produktstatus:


inkl. mva.

100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 16A, 0 N.O. 1 N.C. Auxiliary Contact Configuration, Single Pack

100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 16A, 0 N.O. 1 N.C. Auxiliary Contact Configuration, Single Pack

Egenskaper for produkt/familie

  • Includes space-saving coil-mounted control modules
  • Provides IP2X finger protection
  • Includes electronic and pneumatic timing modules
  • Includes reversible coil terminations (line or load side)
  • Provides front and side mounting of auxiliary contacts
  • Provides reversible coil terminations (line or load side)
  • Meets IEC, UL, and CSA standards requirements
  • RoHs compliant
  • Includes built-in surge suppression
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Offers common accessories for all contactor sizes
Spesifikasjoner
Electrical Standards UL
Actual Life Actual Life Cannot be Calculated (more information)...
Utilization Category AC-3 Squirrel-cage motor starting and stopping
3-Phase kW (50 Hz) 400V/415V Rating 7.5
3-Phase kW (50 Hz) 500V Rating 7.5
Connection Screw Terminals
3-Phase kW (50 Hz) 230V Rating 5.5
3-Phase HP (60 Hz) 575V Rating 15
3-Phase kW (50 Hz) 690V Rating 7.5
3-Phase HP (60 Hz) 460V Rating 10
Coil Voltage 24V DC Electronic Coil
Rated Operating Current, AC-3 16A
Coil Termination Line Side
Terminal Type Screw Terminals
Package Quantity 1
Contact Configuration 0 N.O. 1 N.C. Auxiliary Contact Configuration
Left Side Auxiliary Contact None
Front Mounted Auxiliary Contact None
100-C or 104-C Contactor 2_
Interlock None
Right Side Auxiliary Contact None
Opprinnelsesland CH
Tolltariffnummer 85364190
Lengde 5.11
Høyde 9.5
Livssyklus Active
