IEC 0 100-C Contactor
inkl. mva.
100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 12A, 4 N.O. 0 N.C. Main Contact Configuration, Single Pack
Egenskaper for produkt/familie
- Includes built-in surge suppression with DC coils
- RoHs compliant
- Provides reversible coil terminations (line or load side)
- Includes space-saving coil-mounted control modules
- Includes reversible coil terminations (line or load side)
- Provides IP2X finger protection
- Meets IEC, UL, and CSA standards requirements
- Offers common accessories for all contactor sizes
- Provides front and side mounting of auxiliary contacts
- Includes electronic and pneumatic timing modules
Spesifikasjoner | |
---|---|
Connection | Screw Terminals |
3-Phase kW (50 Hz) 400V/415V Rating | 5.5 |
3-Phase kW (50 Hz) 500V Rating | 5.5 |
3-Phase kW (50 Hz) 690V Rating | 5.5 |
1-Phase HP (60 Hz) 115V Rating | 0.5 |
3-Phase HP (60 Hz) 460V Rating | 7.5 |
3-Phase HP (60 Hz) 575V Rating | 10 |
Terminal Type | Screw Terminals |
Rated Operating Current, AC-3 | 12A |
Coil Voltage | 24V DC Electronic Coil |
No. of Poles | 4 Poles |
Coil Termination | Line Side |
Contact Configuration | 4 N.O. 0 N.C. Main Contact Configuration |
Package Quantity | 1 |
Electrical Standards | UL |
Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
Actual Life | Actual Life Cannot be Calculated (more information)... |
100-C or 104-C Contactor | None |
Front Mounted Auxiliary Contact | None |
Left Side Auxiliary Contact | None |
Right Side Auxiliary Contact | None |
Interlock | None |
Opprinnelsesland | CH |
Tolltariffnummer | 85364190 |
Lengde | 5.11 |
Høyde | 9.4 |
Livssyklus | Active |
Datablad | ||
---|---|---|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
Nedlastinger | ||
---|---|---|
Repair Parts List Filnavn: en-US Filtype: application/pdf |
Last ned | |
MCS 100-C Contactor Photo Filnavn: en-US Filtype: image/png |
Last ned | |
3D Mechanical Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned | |
ABMSA190.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
ABMSA190.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
ABMSA190.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
ABMSA190.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned | |
ABMSA191.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
ABMSA191.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
ABMSA191.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
ABMSA191.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned |
