KONTAKTOR 16A AC3 230V50/60
inkl. mva.
100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 16A, 1 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack
Egenskaper for produkt/familie
- RoHs compliant
- Includes space-saving coil-mounted control modules
- Provides front and side mounting of auxiliary contacts
- Includes built-in surge suppression with DC coils
- Provides reversible coil terminations (line or load side)
- Includes reversible coil terminations (line or load side)
- Meets IEC, UL, and CSA standards requirements
- Includes electronic and pneumatic timing modules
- Provides IP2X finger protection
- Offers common accessories for all contactor sizes
Spesifikasjoner | |
---|---|
Connection | Screw Terminals |
3-Phase kW (50 Hz) 230V Rating | 5.5 |
3-Phase kW (50 Hz) 400V/415V Rating | 7.5 |
3-Phase kW (50 Hz) 500V Rating | 7.5 |
3-Phase kW (50 Hz) 690V Rating | 7.5 |
3-Phase HP (60 Hz) 460V Rating | 10 |
3-Phase HP (60 Hz) 575V Rating | 15 |
Terminal Type | Screw Terminals |
Rated Operating Current, AC-3 | 16A |
Coil Voltage | 230V 50/60Hz |
Coil Termination | Line Side |
Contact Configuration | 1 N.O. 0 N.C. Auxiliary Contact Configuration |
Package Quantity | 1 |
Electrical Standards | UL |
Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
Actual Life | Actual Life Cannot be Calculated (more information)... |
100-C or 104-C Contactor | 1_ |
Front Mounted Auxiliary Contact | None |
Left Side Auxiliary Contact | None |
Right Side Auxiliary Contact | None |
Interlock | None |
Opprinnelsesland | CH |
Tolltariffnummer | 85364900 |
Lengde | 9.601 |
Høyde | 4.902 |
Livssyklus | Active |
